UL-Certified Phosphorus FR ABS Resin: Non-Halogen Safety for High-Temperature Environments
Different generations’ typical properties of thermal conductive PA
| Properties |
Test Method |
Test Condition |
Unit |
Typical Values(dry) |
| Physical properties |
| Specific Gravity |
ISO 1183 |
23°C |
g/cm³ |
1.56 |
| Ash |
ISO 3451 |
800°C,30min |
% |
50 |
| Mechanical properties |
|
| Tensile Strength |
ISO 527 |
5mm/min |
MPa |
210 |
| Tensile Modulus |
ISO 527 |
1mm/min |
MPa |
15000 |
| Elongation at Break |
ISO 527 |
5mm/min |
% |
2 |
| Flexural Strength |
ISO 178 |
2mm/min |
MPa |
350 |
| Flexural Modulus |
ISO 178 |
2mm/min |
MPa |
14000 |
| Unotched Charpy Impact Strength |
ISO 179-1/1eU |
23°C |
kJ/m2 |
100 |
| Notched Charpy Impact Strength |
ISO 179-1/1eA |
23°C |
kJ/m2 |
17 |
| Thermal properties |
| Heat deflection temperature |
ISO 75 |
1.80MPa |
°C |
215 |
| Melt Temperature |
ISO 11357 |
DSC |
°C |
220 |
| Other properties |
| Mold Shrinkage |
internal test method |
flow direction |
% |
0.10-0.20 |
| cross flow direction |
% |
0.60-0.80 |
| Flammability |
ISO 3795 |
- |
mm/min |
30 |
Production Description
Advanced PA6 formulations combine Nylon 6’s inherent strength with nanotechnology enhancements. Carbon nanotube additives (2-5% wt.) improve EMI shielding (40dB attenuation) while maintaining 120MPa tensile strength – critical for drone propellers and 5G antenna enclosures demanding conductivity and lightness.
Key Advantages Over Standard PA6:
-
Retains PA6’s inherent benefits (high strength, abrasion resistance) while addressing weaknesses like moisture sensitivity or brittleness.
-
Competes with metals and more expensive polymers (e.g., PEEK) in high-stress applications.
-
Cost-effective for mass production due to improved processing and performance.
Thermally Conductive PA Product Application
Company Profile
HMT International is a leading global manufacturer and exporter specializing in modified plastics, operating under the brand Chongyuan. Established with a commitment to innovation and sustainability, we engineer high-performance thermoplastic compounds tailored to meet the evolving demands of industries worldwide.
Certified to ISO 9001, ISO 14001, and compliant with RoHS/REACH standards, we align our operations with global sustainability goals while delivering exceptional technical support and supply chain reliability.
3,000+ customized formulations.
500,000+ MT annual production capacity.
25+ years of polymer expertise.
ISO 9001 & ISO 14001 certified facilities.
